Item Description
Chassis (2U) DW800-CBSS
Controller board DW-F850- F850-CTLXSFA
Number of DIMM slot 1
Cache memory DIMM capacity per
controller
16 GiB
Total cache memory capacity per system 32 GiB
Control memory Flash memory: 32 MB
L3 cache memory: 4 MB
SDRAM: 1 GB
Data assurance method Data bus: Parity
Cache memory: ECC (1-bit correction, 2-bit
detection)
Drive: Data assurance code
Available drive slots 24
Physical dimension
(W x D x H) (mm)
483 × 813 × 88 mm
Weight/Mass (kg)
(Approximate)
16.1 kg
Start-up time (min)
1
5 to 8 (min)
Height
(EIA unit)
2
2U
Heat output (W) 218 W
Power consumption (VA) 226 W
Insulation withstand voltage AC 1,500 V (100mA, 1min)
Insulation resistance DC 500 V, 10 MΩ or more
Air ow (m
3
/min)
3
4.0 (m
3
/min)
Notes:
1. Start-up times might be longer depending on the number of drive trays
connected. With a maximum conguration 1 controller chassis and 3 drive trays,
start-up time is approximately 8 minutes.
2. Can be mounted on the Hitachi Universal V2 rack.
Controller chassis with small form-factor drive bays (CBSS)
