8.5.1 Conguration Assistant
8.5.1.1 General overview
Q1
Is this device attached to the
unit?
Q2
Is this device controlling the
unit?
Q3
Is this device used as a Room
Thermostat of a zone?
Q4
How many circuits do you
have?
Q4
How many circuits do you
have?
Q11
How many thermostats are
installed?
Q11
How many thermostats are
installed?
Q12
How are they
connected?
Q5-10
Questions about installation
type
Q5-10
Questions about installation
type
Q5-10
Questions about installation
type
PC-ARFHE as Controller and
wired Room Thermostat of
zones 1 and 2.
PC-ARFHE Controller
PC-ARFHE
Controller and Room
Thermostat of zone
1 (if question 3
answered as "Yes,
Zone 1"), or of zone
2 (if question 3
answered as "Yes,
Zone 2")
Q3
Is this device used as a Room
Thermostat of a zone?
NO
NO
NO
1 1
1 1
Wired
Wireless
0
2 2
2
2
YES, in
Zone 1
YES, in
Zone 1
YES, in
Zone 2
YES, in
Zone 2
YES,
in Both
zones
YES,
in Both
zones
YES
YES
Indoor unit
21
20
21
20
21
20
PC-ARFHE as
Room Thermostat
PC-ARFHE as
SLAVE
PC-ARFHE as
MASTER
Indoor unit
UNIT CONTROLLER
PMML0335A rev.1 - 04/2016
119

Hitachi YUTAKI S80 Series Specifications
