CONSUMABLE PARTS LIST
8-1
CONSUMABLE PARTS LIST
Filter Element
Parts No
Full Flow Filter 4454705
Hydraulic Oil Suction Filter 4479355
Pilot Filter 4294130
Engine Oil Filter 4661289
Fuel Filter 4667073
Water Separator 4667074
Air Cleaner Element 4383875
Bucket Parts
Part No. Quantity
Tooth 4339865 3
Lock Pin 4339868 3
Tooth
Lock Rubber 4339867 3
Side Cutter (R) 4626441 1
Side Cutter (L) 4626442 1
Bolt J921440 6
Spring Washer A590914 6
Side
Cutter
Nut J950014 6
O-ring 4275463 (4)
Shim 4354264 2
NOTE: The quantities shown in the above tables are
those required for the one standard bucket. The
quantities for an optional bucket may differ. The
figures in ( ) in the O-ring columns include the
O-ring quantities used at the joints between the
arm and the link. Shims are used to adjust the
clearance at the joint between the arm and
bucket.
