OPERATOR’S STATION
1-5
Engine Oil Pressure Indicator
The red indicator will light when the engine oil pressure
is low. If the red indicator comes ON, the engine oil
pressure warning buzzer will sound at the same time.
Immediately stop the engine. Check the engine oil
pressure system and the oil level for any abnormality.
Hour Meter
Total (accumulated) machine operation hours counted
since the machine started working, are displayed in the
unit of HOUR (h). One digit after the decimal point indi-
cates the tenths of an hour (6 minutes).
Fuel Gauge
The gauge needle position indicates the fuel level. Refill
the fuel before only the E-marked segment comes ON.
Coolant Temperature Gauge
The gauge needle position indicates the engine coolant
temperature. Coolant temperature is normal when the
needle stays in white zone while operating.
M178-01-037
M1MS-01-008
M1MS-01-007
M1MS-01-006
To Next Page
