Memory Preset - Data Save/Load
Memory Preset - Data Save/Load:
The Save Data and Load Data programs make it easy to store and load charge and
discharge pro les for up to 10 batteries per channel. Data can be saved for each
battery type and each charge mode available with the X1 mini. This allows you to
recall data for each battery when charging or discharging without having to set up
the program over again. You can also edit settings for each saved battery.
Save Data:
From the BATT/PROGRAM menu use the + or ▬ buttons
to scroll to the BATT MEMORY program and press the
ENTER/Start ► button to enter the battery memory program. In the corner of
the screen you will see the number 1 ashing, use the + or ▬ buttons to scroll
to scroll through the memories. When you are ready to select a memory to
program, press the ► button again to enter the memory setup menu.
Press the ► button again and the battery type will begin
to ash. Use the + or ▬ buttons to select the battery type
(LiPo, LiFe, LiIon, LiHV, NiMH, NiCd or Pb, then press the ► button to con rm
your selection.
Now you will use + or ▬ buttons to scroll through the battery parameters, using
the + you will make adjustments in the following order, using the ▬ button will
reverse this order.
Voltage and Number of Cells: Press the ► button and
the number of cells will begin to ash. Use the + or ▬
buttons to change the cell count then press the ► button to con rm your selection.
Charge Current: Press the ► button and the charge
current value will begin to ash. Use the + or ▬ buttons
to change the charge current then press the ► button to con rm your selection.
Discharge Current: Press the ► button and the discharge
current value will begin to ash. Use the + or ▬ buttons
to change the discharge current then press the ► button to con rm your
selection.
[BATT MEMORY 1]
ENTER SET ->
BATT TYPE
LiPo
BATT VOLTS
7.4V ( 2S )
CHARGE CURRENT
4.9A
DSCH CURRENT
2.0A
Per Cell Discharge Voltage: Press the ► button and the
per cell discharge voltage value will begin to ash. Use
the + or ▬ buttons to change the per cell discharge voltage, then press the ►
button to con rm your selection.
MAKE SURE TO FOLLOW YOUR BATTERY MANUFACTURERS
RECOMMENDATIONS REGARDING DISCHARGING. FAILURE TO DO SO
MAY DESTROY THE BATTERY OR RENDER IT UNSAFE FOR USE.
Terminal Voltage: Press the ► button and the terminal
voltage value will begin to ash. Use the + or ▬ buttons
to change the terminal voltage, and then press the ► button to con rm your
selection.
CHANGING THE TERMINAL VOLTAGE IS ONLY INTENDED FOR EXPERT
USERS, ANY CHANGES TO DEFAULT SETTINGS ARE COMPLETELY AT YOUR
OWN RISK.
Save Program: Press the ► button to save the program.
SAVE….. will appear momentarily while the program is
written to the memory.
Once saved the screen indicate the memory number,
battery type, cell count, charge current and discharge
current.
Recall Memory:
From the BATT/PROGRAM menu use the + or ▬ buttons to
scroll to the BATT MEMORY program and press ► button
to enter the battery memory program . Use the + or ▬ buttons to scroll to scroll
through the memories. When you have found the memory you would like to use
press and the ► button again to recall the memory.
Use the + or ▬ buttons to scroll the available proceses
(charge, discharge, balance charge etc.). Select the process
you would like to execute for the battery then press and hold the ► button for 3
seconds to begin the selected process.
Memory Preset - Data Save/Load [cont.]
DSCH VOLTAGE
3.0V/CELL
Warning
TVC = YOU R RISK
4.20V
Warning
SAVE PROGRAM
ENTER
SAVE PROGRAM
SAVE...
[ BATT MEMORY 1 ]
LiPo 7.4V (2S)
[ BATT MEMORY 1 ]
C:4.9 D:2.2 A
ENTER CHARGER
LOAD...
LiPo BALANCE CHG
4.9A 7.4V (2S)
