Hitron CDA-RES User’s Guide
1.3 LEDs
This section describes the CDA-RES’s LEDs (lights).
CABLE Use this to connect to the Internet via an F-type RF
cable.
POWER Use this to connect to the 12v/2A power adapter that
came with your CDA-RES.
NEVER use another power adapter with your
CDA-RES. Doing so could harm your CDA-RES.
Figure 3: Power Adapter
Table 2: Hardware Connections
