Hitron CDA-RES User’s Guide
Frequency (MHz) This displays the actual frequency in Megahertz (MHz)
of each upstream data channel to which the CDA-RES
is connected.
Modulation This displays the type of modulation that each upstream
channel uses.
Signal Strength
(dBmV)
This displays the power of the signal of each upstream
data channel to which the CDA-RES is connected, in
dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
upstream data channel to which the CDA-RES is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Cable Modem IP Information
IP Address
This displays the CDA-RES’s WAN IP address. This IP
address is automatically assigned to the CDA-RES.
Subnet Mask
This displays the CDA-RES’s WAN subnet mask.
Gateway IP
This displays the IP address of the device to which the
CDA-RES is connected over the CABLE interface.
DHCP Lease Time This displays the time that elapses before your device’s IP
address lease expires, and a new IP address is assigned
to it by the DHCP server.
Table 9: The Cable: Status Screen (continued)
