HK Audio LUCAS NANO 305 FX User Manual

LUCAS NANO 305 FX 1.1
13
6 Technical Specifi cations
LUCAS NANO 305 FX System
Total power output (RMS)¹ 230 W Class D
Calculated peak power 750 W
Frequency response –10 dB 44 Hz – 20 kHz
Active protective circuits MultiBand Limiter, Subsonic Filter,
Thermo Protection, Overload Protection
Special Features 5-Channel Mixer, 2-Band EQ for Channels
1-3, 7 Reverb E ects, Bluetooth Audio
Streaming
Enclosure Coated polypropylene
Optional accessories S-Connect Pole LN (signal-routing
speaker pole), Stereo Stand Add-on 300
Series, Roller Bag 300 Series (padded
trolley), Desk/Wall Mount Add-on, Link
Cable
Weight 10.3 kg / 22.7 lbs.
LUCAS NANO 305 FX Subwoofer
Max SPL peak² 118 dB
Frequency response –10dB 44 Hz - 190 Hz
Inputs 3x Combination 1/4" (6.3 mm)/XLR Ports,
2x 1/4" (6.3 mm) Jacks/Stereo Mini-Jack,
Bluetooth In, Link In (for Twin Stereo
Mode)
Outputs Speaker Out, Easy-Click, Thru, Link Out
(for Twin Stereo mode)
Bass woofer 8"
Pole mount M33 for the (signal-routing) S-Connect
Pole LN, a speaker pole adapter sleeve
(M33 to M20) is included
Dimensions (WxHxD) 30 x 39 x 42 cm
Weight 8.3 kg / 18.3 lbs.
LUCAS NANO 300 Series Satellite
Max SPL peak² 120 dB (Satellite Array)
Frequency response –10dB 190 Hz – 20 kHz
Woofer 3,5"
Horn directivity 60° x 40° (Single Satellite)
60° x 30° (Satellite Array)
Inputs Speaker In, Easy-Click
Pole Mount Adapter 3/8" thread
Dimensions (WxHxD) 13 x 13 x 11.5 cm
Weight 1 kg / 2.2 lbs.
General Technical Specifi cations
Current consumption
pursuant to EN 60065³
1.1 A / 100-240V AC
Inrush current 46 A at 120 V and 230 V
¹ Short-term RMS value measured using a sine burst signal with a 1/4 cycle rate and a resulting crest
factor of 9 dB at a frequency that is representative of the system
² @10% THD, Halfspace
³ Current consumption (mains power) was measured at the internal amplifier’s output at 1/8power
by inputting a sine wave as specified in the EN60065 standard. This value represents the average
current drawn from the mains grid when operating the system with standard musicsignals.
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Stamer Musikanlagen
GmbH is under license.
For USA:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
End users must follow the specific operating instructions for satisfying RF exposure compliance. This
transmitter meets both portable and mobile limits as demonstrated in the RF Exposure Analysis. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter
except in accordance with FCC multi-transmitter product procedures.
For Canada:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of
a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
