LUCAS NANO 305 FX 1.1
12
5 Aiming Satellites
5.1 Vertical Alignment
The vertical directivity of a single LUCAS NANO 300 Series satellite in
stereo mode is +20° x -20°. Vertical directivity changes to 30° when you use
the two satellites in an array.
-15°
+15°
-20°
+20°
Single
Satellite
Satellite
Array
Always line up LUCAS NANO 305 FX satellites with the audience’s ear level
to achieve the most balanced audio image.
5.2 Horizontal Alignment
The satellites’ horizontal dispersion angle is around 60°. Depending on
room size and whether it’s a mono or stereo setup, you may want to turn
the satellites in towards the audience area.
Stereo
Mono
