２．InitialSet‑Up
−29−
InitialSet‑UpConfiguration:unitofmeasureforpressure,wastegatetype,andtarget
boost.Thecharacteristicsoftheboostchangeforeachvehiclecanbememorizedbythe
EVC.WhenusingtheEVCforthefirsttime(orafterareset)theinitialset‑upwill
beautomaticallystarted.Followtheprocedurebelowfortheinitialsetting.
２．１．SettingthePressureUnitofMeasure
２．２．SettingtheExhaustBypassType
(１)Turnthevolumeknobandselectthepressureunitof
measurefrom"PAS(kPa)"or"PSI."
・Thedigitaldisplay(S)willdisplay"".
(２)Pressthevolumeknobafterselectingtheunit,Goto
2.2forsettingtheexhaustbypass(wastegate)type.
(１)Turnthevolumeknobandselecttheexhaustbypass
typefrom"‑S‑"fortheswingvalvetypeor"‑P‑"for
thepoppetvalvetype.
・Thedigitaldisplay(S)shows"".
(２)Pressthevolumeknobafterselectingtheexhaust
bypasstype.Goto2.3forsettingthestandardmax
boostsetting.
２．３．SettingtheStandardMaximumBoostSetting
(１)Turnthevolumeknobandsetthemaxbaseline/
defaultboostvalueiftheboostvalueisknown.
Ifnot,drivethevehicleunderloadtoachievethe
maximumboostvalue.Thevaluewillthenbeshown
inthedigitaldisplay(S).
・Thespeed/RPMdisplayshows"".
・Thedigitaldisplay(L)showsthecurrentboost
value.
・Enterthemaxboostvaluethatisstable.
(２)Pressthevolumeknobwhenthedigitaldisplay(S)
isshowingthemaxbaseline/defaultboostvalue.
Goto2.4forsettingthetargetboost.
ActionKey
：Press ：TurnVolume
：Pressandholdfor1sec.
Formostfactoryturboapplications,theactuatortypeisused;therefore,theexhaust
bypasstypeistheswingvalvetype.Formostlargecapacityturboapplications,the
externalwastegateisused;therefore,theexhaustbypasstypeisthepoppetvalvetype.
Themaximumbaseline/defaultboostafterinstallingtheEVC.
