HMF-IRC Instruction Manual - GB
01-01 HMF TECHNICAL SERVICE DEP.
10
3.2.3 Press Buttons and Tumbler Switches
All press buttons and tumbler switches on the remote control box only control
“ON/OFF”-functions in the IRC-system.
3.2.3.1 Remote Control of RCL Functions
On the RCL controller, different functions can be operated by means of the
three press buttons; red, yellow and green. These functions can also be remote
controlled by means of the press buttons on the right side of the remote control
box. However, there are only two press buttons.
The functions of the green and red press buttons are operated directly, while
the function of the yellow press button is operated by pushing the left tumbler
switch to the right (opt. 1) and at the same time pushing the red press button.
The following functions are operated by means of the press buttons:
Green press button: Activation of the RCL-system / Deactivation of buzzer
Red press button: Override / Manual activation of HDL / Indication of errors
Yellow press button: Alternative function mode.
These RCL functions are thoroughly described in the RCL Instruction Manual.
