HMF-IRC Instruction Manual - GB
01-01 HMF TECHNICAL SERVICE DEP.
11
3.2.3.2 Engine Throttle Control (Option)
Throttle control of the engine of the vehicle can be carried out from the remote
control box. The regulation area is between idling and a max. number of
revolutions fixed by the HMF service point and programmed in the EDC-engine
control by the supplier of the vehicle.
Operate the throttle control in the following way:
• The left tumbler switch must be in central position
• By pushing the right press button several times, the number of revolutions is
increased (+ RPM) stepwise
• By pushing the left press button several times, the number of revolutions is
decreased (- RPM) stepwise
