GENERAL INFORMATION
Service +49(0)391 2514666 02/2017 Instruction Manual HMP LFGpro – en
3
Legal terms of reference
The Light Weight Deflectometer complies with the current state of the art and
all applicable safety regulations.
The LWD meets the basic safety requirements laid down in the EU Directives
for Harmonisation referenced in the EC Certificate of Conformity.
Construction and function of the LWD meet the requirements laid down in
»Technical Test Code for Soil and Rock in Road Construction TP BF – StB
Part B 8.3 / Issue 2012« and »ASTM E2835-11 – Standard Test Method for
Measuring Deflections using a Portable Impulse Plate Load Test Device«.
Intended Use
The Light Weight Deflectometer is exclusively intended for determining the soil
bearing capacity and the compaction quality of the soil referred to »Technical
Test Code for Soil and Rock in Road Construction TP BF – StB Part B 8.3 /
Issue 2012« and »ASTM E2835-11 – Standard Test Method for Measuring
Deflections using a Portable Impulse Plate Load Test Device«.
Its intended use also includes:
❙ Compliance with the safety instructions and safety regulations contained in
this operating manual;
❙ Compliance with the maintenance and servicing instructions contained in
this operating manual.
Any other use or any use beyond this definition is not intended and may cause
injury to people and damage to property.
The manufacturer/supplier shall not be held liable for damages resulting from
other than the intended use. The risk shall be borne solely by the user.
Technical Terms of Reference / Transport
To avoid damage to the unit and prevent accidents during transport the Light
Weight Deflectometer is provided with a transportation lock which is fixed to
the guide tube during transport.
The LWD is equipped with a transportation lock designed to avoid
damage to the instrument and make sure that it can be safely
transported and handled. This lock must be used to secure the drop-
weight on the guide tube whilst the equipment is moved from job to
job.
The drop height determined for the drop-weight by calibration ( calibration
record) has been preset. The drop height is secured against changes and
must not be altered by the user.
Engage the drop-weight in the release mechanism prior to any test. To release
the drop-weight, just actuate the release mechanism.
Prior to any measurement, test the release mechanism to be sure it
functions as necessary.
Support the drop-weight by hand after every impact to avoid faulty
measurements.
