HMS Anybus AS-Interface Master - 2 Applicable Anybus Products; 3 Requirements

How to configure an Anybus AS-Interface Master module
SCM-7032-036
Rev 1.02
www.anybus.com HMS Industrial Networks AB Page 5 (19)
2 Applicable Anybus products
The following table specifies the relevant Anybus products for this document.
Description Name / Type
Anybus-M Master AS-Interface (Module software version higher than 2.04)
Anybus-M Master PCI AS-Interface (Module software version higher than 2.04)
Anybus X-gateway Master AS-Interface (Module software version higher than 2.04)
3 Requirements
The following equipment is needed to setup a successful configuration.
Description Name / Type Version
Terminal software HyperTerminal, TeraTermPro 5.1, 2.3
X-gateway Interface Addendum X-gateway AS-Interface Master
Interface Addendum
2.10
X-gateway User Manual X-gateway User Manual 1.11
Master Fieldbus Appendix Anybus-M Master AS-Interface
Fieldbus Appendix
2.00
Power supply 24VDC n.a. n.a
Configuration cables n.a. n.a.
