7
TO CONNECT A POWDER OR SOLID DETERGENT
DISPENSER:
– Break out perforated disk at the tank panel (either at the right
or left side).
– Drill a hole through the inner tank wall appropriate to the
required connection diameter.
– Screw up tightly the dosing connection with tank wall.
– Connect the plug (C) of the wire harness with the dosage pump
(max. 100 VA).
– Close control box and put panel(s) back into place.
Switch on main switch at site or put the plug in.
Dispenser adjustment see chapter 6.1.
CONDUCTIVITY PROBE:
– Conductivity probe should be installed at the flat part of tank
bottom (same tank where dosage is connected to) (see fig.).
– The hole size should be appropriate to the conductivity probe.
C
