INSTRUCTION MANUAL FOR DISHWASHERS
Page 3 of 15
GB
Mod.
V~
2.3 Electrical connection
•
There must be an omnipolar type of main
switch that disconnects all contacts, including
the neutral, with a distance of at least 3 mm
between the open contacts and with safety
cuit breaker tripping or connected with
, to be sized or calibrated in conformity with
the power indicated on the machine’s data plate.
•
The main switch must be located on the electric
line close to the installation, and it must serve only
one appliance at a time.
•
Electric network voltage and frequency must
coincide with those given on the data plate.
•
There must be an effective earthing system in
conformity with the prevention standards in force
for operator and equipment safety.
• The power supply cable (type H07RN-
not be pulled or crushed during normal operation or
The unipotential terminal fastened to the body must
be connected to a unipotential cable having a
section suited to the application.
• Respect the polarities in
Consult that attached wiring diagram for additional
information.
Do not use adaptors, multiple socket-
outlets or cables of inadequate type and
section or with extension connections not compliant w
The appliance is to be connected to the water network
with a hose. There must be a slide on-
able to quickly and completely turn off the
between the water network and the
appliance’s solenoid valve. The on-
the line near and right before the appliance.
•
If the system is new or barely used, have the water run a long time before making the
connection.
• The water supply, temperature and pressure must be compatible
with what is indicated on the
machine’s technical data plate.
•
If the water’s hardness is greater than 14 F (8 dH), we recommend you use the machine with
internal water softener (available on request).
If the water’s hardness is greater than 35 F (19.5
dH), we recommend you install an external water softener upline of the solenoid valve.
