OM-281997 Page 9
SECTION 3 – SPECIFICATIONS
Viewing Field 3.94 x 2.36 in. (100 x 60 mm)
Reaction Time 0.00004 sec (1/25,000 sec)
Available Shades Darkened State: No. 9–13/Light State: No. 3
Provides Continuous UV And IR Protection (DIN 15)
Grind Mode Yes
Sensitivity Control Lo-Hi Adjustment For Varying Ambient Light And Welding Arc
Delay Control Min-Max Adjustment Slows Lens Dark-To-Light State Between
0.1 And 0.9 Seconds
Power Auto-On/Auto-Off
Low Battery Indicator Red LED Light Illuminates To Indicate 2-3 Days Remaining
Battery Life
Power Supply Solar Cell And Two Replaceable CR2450 Lithium Batteries
Sensors Independent/Redundant (Four)
Operating Temperature 14°F to 149°F / -10°C to +65°C
F
When stored in extremely cold temperatures, warm hel-
met to ambient temperature before welding.
Total Weight 19.7 oz (560 g)
Standards ANSI Z87.1-2015, CE EN379, CSA Z94.3-15
Warranty Two Years From Date Of Purchase (see Section 11)
