OM-281997 Page 17

SECTION 6 – REPLACING LENS COVERS

6-1. Replacing Outside Lens Cover

OM-281997 Page 7

SECTION 12 REPLACING THE LENS COVERS

12-1. Replacing Outside Lens Cover

Never use the auto-

darkening lens with-

out the inside and

outside lens covers

properly installed.

Welding spatter will

damage the auto-

darkening lens and

void the warranty.

1 Locking Tab

2 Lens Assembly

3 Outside Lens Cover

Remove lens assembly by

sliding the locking tab to the

left. Remove cartridge and

lens cover.

Install new lens cover. Install

lens assembly and slide lock-

ing tab to the right.
