4.PackageContents

5.Installation
Thecontrollermustbemountedontheplatformoftheairframebyusingoneoftheprovideddoublesidedtapes.
Itcanbeattachedflatorupright,andevenupsidedownundertheplane.Youjustneedtomakesurethe
longerside of theunitisalong withthe heading direction,the side ofpins canbe puteitherforwardsor
backwards.Theillustrationshowsyou4differentmountorientations.Afterinstallation,remembertochoosethe
correctsettingintheprogramcardorPCconfigtool. Asthecontrollerisdesignedforbalancing,pleasemake
surethatthemountingplatformshouldbeparalleltothehorizonandlocatethecontrollerasclosetotheCGas
possible.Inordertooffsetthedeviationofinstallationyouneedtoperformalevelcalibrationafterinstallation.


