Refit the air supply hose with new clips (75). Clips
should be crimped closed using pinsers. Crimp gap will
vary due to spring back and hose type but will not be
less than 0.6 mm (0.025 in).
Suitable alternative hose clamps can be used.
HX25/25W/27W Service Repair Manual Component Testing and Replacement
4:20
Caution
Before mounting turbocharger on engine, check for
full and free wastegate movement.
Caution
Ensure that air feed pipe is free from kinks and has no
chafe marks.
