Holux RCV-3000 - Physical and Interface Specifications; Input;Output Interface; Physical Characteristics; Other Functions

8
• Input/ Output Interface:
I.
Compatible Bluetooth Serial Port Profile (SPP), Version1.2 and class 2
(up to 10 meter range).
II. In/Out Port. GPS signal (Out)/ Command
(In) with USB Level Mini USB
Type B Connector.
Physical
• Size: 62.5 × 41 × 17.1 mm
• Weight: < 53 g
• Operating Temperature: -10°C to + 60°C (under the un-
charging condition);
Charging Temperature: 0°C to + 45°C
• Storage Temperature: -20°C to + 60°C
• Operating humidity: 5% to 95% No condensing
Other Functions
• Bluetooth frequency: 2.4 ~2.48GHz
• Bluetooth Input Sensitivity: -85dBm
• Low sensitivity of receiving satellite signal: -165 dBm
• LED Functions: Indicate Bluetooth status, GPS status, Battery Status and
Battery charging status
• RF Frequency range: 2402~0480Mhz
Max output power: -30dBm
