TECHNIC
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 22
TK 255
13 TECHNIC
13.1 Components
TK 255
1
Work table
16
Locking lever angle adjustment
2a/2b
Guide rail stop
17
Handwheel height adjustment
3
Saw blade guard
18
ON / OFF switch
4
Attachment saw blade guard
19
Tool box
5a
Dust collector hose
20
Scale miter gauge
5b
Dust collector plug
21
Locking handle miter gauge
6
Riving knife
22
Miter gauge
7
Saw blade
23
Locking lever riving knife
8
Table insert
24
Stop rail
9
Rip fence
25
Scale rip fence
10
Guide rail table width extension
26
Scale table extension
11
Table extension
27
Support for spare saw blades
12
Locking lever rip fence
28
Slot 28a/28b/28c
13
Sight glass
29
Wrench
14
Push stick
30
Allen key
15
Lock table extension
31
Cable hook
13.2 Technical details
TK 255
Voltage
230 V / 50 Hz
Motor power
2000 W
Idle speed
4800 min
-1
Saw blade
Ø 254 x Ø 30 x 2,8 mm / 60Z
Work table
940 x 642 mm
Cutting height max.
90°: 80 mm 45°: 50 mm
Height adjustment
0 – 80 mm
Saw blade swivel range
0 -45°
Dust collector plug
Ø 40 mm
Weight
28 kg
Sound pressure level L
PA
92,6 dB(A) K: 3dB(A)
Sound power level L
WA
105,6 dB(A) K: 3dB(A)
