OPERATION
HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at 29
TK 255
16.2.5 Table extension (Fig.15)
 The table width extension (11) should always be used for particularly wide work pieces.
 Loosen the locking handle (15) and pull out the table width extension enough so the work
piece can lie on it without tilting.
16.2.6 Angle stop (Fig.16)
 Push the cross stop (22) into a slot (2a/2b) on the saw table.
 Loosen the locking handle (21).
 Rotate the cross stop (22) until the required angle is set. The scale (20) shows the set
angle.
 Re-tighten the locking handle (21).
16.2.7 Overload protection (Fig.3)
W ARN I NG
This electrical machine is provided with an overload protection!
In case that the overload protection was initiated, proceed as follows:
 Disconnect the machine from the power supply
 Allow the machine to cool down
 Check the machine carefully for possible damages.
 Have damages repaired before re-starting the machine!
 Connect the machine to the power supply.
 Push the overload switch (k)
16.2.8 Auxiliary tools stored (Fig. 21/22/23)
 Loose M6 plastic knob(27)if there is a spare saw blade(7), then hang saw blade (7) in,
tighten M6 plastic knob(27)
 Put rip fence(9) on slot (28a)
 Put push stick(14) or stop rail (24) on slot(29b)
 Coil cable on hook(31)
 Put 2Xwrench(f) and Allen key(30) on tooling box(19)
 Put the whole mitre gauge on slot (28c)
