HOMCOM A90-282V70 - Assembly

1.Carry out the machine from the package by two persons and place it lightly on flat floor,
and put other fittings beside the machine.
2.Lift up the upright tube according to the picture and lock it with 2pcs M10 knob screws at
two sides.
III.ASSEMBLY
NOTICE: ASSEMBLY REQUIRES TWO PERSONS
STEP 1
Main part
Name Q'ty
1.Main frame 1set
No. Fittings Qnty No. Fittings Qnty

M8 Knob
2
⑦
Multi
Wrench
1

M10
Knob
2
⑧
6mm Wrench
1

M6*15
2
⑨
Silicone oil
1
④
ST4.2*16
1
⑩
Safety Key
1
⑤
Cup Holder
1 ○
11
User’s
Manual
1
⑥
Ipad Holder
1
7
