5
2. Upper shaft
3. Guide recess
4. Button
5. Knob
6. Lower shaft
7. PRO-CUT I - Fixed line head
8. Grass shield
9. Cutting line
15. Lock out lever
16. On/Off switch
17. Throttle trigger
18. Primer bulb
19. Starter grip
Figure 2
1. Front handle
2. Upper shaft
10. Wing nut
11. Bolt
Figure 3
8. Grass shield
12. Bolt
13. Flat washer
14. Wing nut
Figure 4a – 4b
20. Full choke position (choke on)
21. Half choke position
22. Run position (no choke)
Figure 7
23. Latch
24. Air lter element
25. Air box cover
Figure 9
26. Spark plug boot
27. Spark plug
ASSEMBLY
UNPACKING
The product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
■ Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
SPECIFICATIONS
Weight without fuel
and trimmer head
4.50 kg
Weight without fuel
with trimmer head
4.72 kg
Fuel tank volume 250 ml
Cutting swath 432 mm
Diameter of cutting line 2.4 mm
Engine displacement 26 cc
Maximum engine performance
(in accordance with ISO 8893)
0.65 kW
Maximum rotational frequency of
the spindle
12000 min
-1
Engine speed (rotational
frequency) at idle
2800-3800 min
-1
Fuel consumption (in accordance
with ISO 8893) at max. engine
performance
0.37 kg/h
Specific fuel consumption (in
accordance with ISO 8893) at
max. engine performance
0.57 kg/kw.h
Vibration level - Idling
Front handle 3.3 m/s
2
Rear handle 3.4 m/s
2
Vibration level - Racing
Front handle 9.2 m/s
2
Rear handle 8.3 m/s
2
Measured sound pressure level (in accordance with
EN ISO22868)
Idle
82.7 dB(A)
K
pA
=3 dB(A)
Racing
103.1 dB(A)
K
pA
=3 dB(A)
Measured sound power level (in accordance with EN
ISO22868)
Idle
90.0 dB(A)
K
WA
=3 dB(A)
Racing
107.9 dB(A)
K
WA
=3 dB(A)
DESCRIPTION
Figure 1
1. Front handle
