6
shaft (item 2).
■ Loosen the knob (item 5) by turning it counter
clockwise.
■ Align the button (item 4) on the lower shaft ( item 6 )
with the guide recess (item 3) on the upper shaft.
■ Slide the lower shaft into the upper shaft until the
Lower shaft clicks into place.
■ Tighten the knob securely by turning it clockwise.
WARNING
Improper assembly could result in serious personal
injury.
REMOVING THE LOWER SHAFT FROM THE UPPER
SHAFT.
Follow these steps to remove the lower shaft from the
upper shaft.
■ Loosen the knob by turning it counterclockwise.
■ Push the button while pulling out the Lower shaft.
ATTACHING THE FRONT HANDLE
See gure 2.
■ Loosen and remove the bolt (item 11) and wing nut
(item 10) from the upper handle (item 1).
■ Install the front handle onto the upper shaft (item 2) at
the position between foam and warning label.
■ Replace the bolt and wing nut. Tighten the wing nut
securely.
SAFETY GUARD
See gure 3.
■ Remove wing nut (item 14), flat washer (item 13) and
bolt (item 12) from the owner's kit.
■ Place safety guard (item 8) over shaft and bracket.
■ Install bolt through the slots in the tabs on safety guard
and bracket on driveshaft housing.
■ Install flat washer and wing nut.
■ Tighten securely.
ATTACHING THE PRO-CUT I HEAD
■ Remove the paper tube
■ Install PRO-CUT I head assembly on drive shaft.
Secure with spool retainer.
OPERATION
FUEL AND REFUELING
Handling the fuel safely
Always handle fuel with care, it is highly flammable.
■ Always refuel outdoors where there are no sparks and
flames. Do not inhale fuel vapors.
■ Do not let petrol or oil come in contact with your skin.
■ Keep petrol and oil away from the eyes. If petrol
or oil comes in contact with the eyes, wash them
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
PACKING LIST
1. Trimmer (1 unit)
2. Lower shaft assembly (1 pc)
3. Front handle assembly (1 pc)
4. Safety guard assembly (1 pc)
5. PRO-CUT I head and cutting head assembly (1 pc)
6. Combination wrench (1 pc)
7. 2-Stroke Lubricant (1 bottle)
8. Operation manual (1 pc)
WARNING
If any parts are damaged or missing, do not operate the
product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
WARNING
Do not attempt to modify the product or create
accessories not recommended for use with the product.
Any such alteration or modication is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.
WARNING
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.
WARNING
Never attach or adjust any attachment while power
head is running. Failure to stop the engine may cause
serious personal injury.
WARNING
Be certain the knob is fully tightened before operating
the product. Check it periodically for tightness during
use to avoid serious injury.
ATTACHING THE POWER HEAD TO THE TRIMMER
ATTACHMENT
See gure 1.
Follow these steps to connect the lower shaft to the upper
To Next Page
