Start-up
• Connect the bus line to the bus connecting ter-
minals (see figure 7+8). To connect and loosen
the single wires, press the orange clamp using a
small screwdriver.
• Put the green push-in terminal back into the
mounting plate (see figure 8).
• Place the mounting plate (D) in the flush-
mounted box and fasten it to the flush-mounted
box using the screws supplied (see figure 11).
• Place the electronic unit (C) of the presence sen-
sor into the mounting plate by fully snapping the
connection pins into the appropriate bracket of
the mounting plate (see figure 12).
• Switch the Homematic IP wired bus on again to
activate the teach-in mode of the device (see “6.4
Teaching-in” on page 50).
6.4 Teaching-in
Please read this entire section before starting
the teach-in procedure.
Please refer to the Homematic IP Wired System
Manual for detailed information on setup and
control options.
To integrate the device into your system and enable it to
communicate with other devices, you must teach it in first.
You can use the following set-up and control options
:
