58
Maintenance and cleaning
10 Maintenance and cleaning
The product does not require any maintenance.
Enlist the help of an expert to carry out any
repairs.
Clean the device using a soft, lint-free cloth that is clean
and dry. Do not use any detergents containing solvents,
as they could corrode the plastic housing and label.
11 Technical specifications
Device short name:
HmIPW-SPI
Supply voltage: 24 VDC, +5 % -20 %, SELV
Current consumption: 5 mA max.
Standby power consumption: 45.6 mW (1.9 mA)
Cable type and cross section Rigid cable
0.12-0.50 mm²
Installation: only in normal commer-
cial switch boxes (device
boxes) in accordance
with DIN 49073-1 or in
the installation adapter.
Degree of protection: IP20
Protection class: III
Ambient temperature: -5 to +40 °C
Dimensions (ø x H) 100 x 45 mm
Weight: 92 g
