48
Start-up
6.2 Ceiling installation
For the installation on the ceiling, please proceed as fol-
lows:
Disconnect the corresponding line of the
incoming Homematic IP wired bus.
Select a mounting location at that point where
the bus cable is led out of the ceiling.
Mark the two bore holes (G) to the mounting
location in a distance of 40 mm (see fig. 3).
Drill the holes marked and insert the supplied
plugs (see figure 3).
If you are working with a stone wall, drill the
marked two 5 mm holes and insert the plugs
supplied. If you are working with a wooden wall,
you can pre-drill 1.5 mm holes to make screws
easier to insert.
Feed the bus cable through the cable bushing (F)
of the installation adapter (see figure 4).
Mount the installation adapter by screwing the
supplied screws (3.0 x 30 mm) into the plugs (see
figure 5).
To facilitate the connection of the bus line to the
terminals of the presence sensor, remove the
green push-in terminal from the device. Press the
latch on the back of the mounting plate next to
the lock symbol and slide the clamp out of the
