Honda 08E91-E54-100 - Page 4

4 of 25 AII 50024-50373 (1308) © 2013 American Honda Motor Co., Inc. – All Rights Reserved.
7. To prevent the clips from falling into the vehicle body,
roll up a shop towel, and insert it between the driver’s
A-pillar and the dashboard. Be careful not to damage
the A-pillar trim.
Q0N2015BG
SHOP
TOWEL
DRIVER’S
A-PILLAR
DASHBOARD
8. Remove the driver’s A-pillar trim. Remove the shop
towel and any clips that fell from the A-pillar. 
NOTE: The upper clip will
stay in the body.
Q0N2016AG
UPPER CLIP
DRIVER’S 
A-PILLAR TRIM
(Remove.)
DRIVER’S
A-PILLAR
TRIM
9. Remove the upper clip from the driver’s 
A-pillar.
Q0N2017AG
Push 2 tabs.
UPPER CLIP
(Discard.)
DRIVER’S
A-PILLAR
10. Temporarily reinstall the driver’s A-pillar trim. Check
the overlap between the headliner and the trim,
according to service manual specifications. Remove
the trim, and install the new clip (supplied).
Q0N2018AG
DRIVER’S 
A-PILLAR TRIM
(inside)
NEW CLIP
