22
CONTROLS AND FEATURES
Starter Grip
Pulling the starter grip operates the
recoil starter to crank the engine for
starting.
The “Neutral Starting System”
prevents the starter rope from being
pulled out for starting the engine
unless the gearshift lever (P.19) is set
in the N (neutral) position.
The engine will start only when the
emergency stop switch clip is in the
emergency stop switch.
Engine Cover Latch
The engine cover latch fastens the
engine cover to the outboard motor.
Do not remove the engine cover
while the engine is running.
Transom Angle Adjusting Rod
The transom angle adjusting rod
adjusts the transom angle of the
outboard motor when fully lowered.
Proper adjustment prevents the
outboard motor from being adjusted
too low (p. 53).
Direction to pull
STARTER GRIP
TRANSOM ANGLE
ADJUSTING ROD
