Honda BF4A - Engine Cover Removal and Installation

61
SERVICING YOUR OUTBOARD MOTOR
ENGINE COVER REMOVAL
AND INSTALLATION
To remove, unlatch the engine cover
latch and slide the engine cover
forward. Unhook the engine cover
hook as shown. Remove the engine
cover while turning a starter grip to
the upward.
To install, lower the engine cover
while turning a starter grip to the
upward. Hook the engine cover hook
as shown, and latch the engine cover
latch.
ENGINE COVER LATCH
UNLOCK
ENGINE COVER
STARTER GRIP
ENGINE
UNDER
COVER
ENGINE
COVER
HOOK
ENGINE COVER
STARTER GRIP
ENGINE
COVER
HOOK
ENGINE
UNDER
COVER
