21
CONTROLS AND FEATURES
(BF4A)
(BF5D and BF6A)
LEVER POSITION FUNCTION
ON Fuel from the internal fuel tank is supplied.
OFF Fuel supply is shut off.
Set the fuel valve lever to the “OFF”
position during transporting or storing the
outboard motor.
LEVER POSITION FUNCTION
INTERNAL FUEL
TANK
Fuel from the internal fuel tank is supplied.
PORTABLE FUEL
TANK
• Fuel from the portable fuel tank is
supplied.
• If the portable fuel tank is not
connected, fuel supply is shut off.
Set the fuel valve lever to the
“PORTABLE FUEL TANK” position
during transporting or storing the
outboard motor.
Fuel Filler Cap Vent Knob
(Internal Fuel Tank)
The fuel filler cap is provided with a
vent knob to seal the fuel tank. Open
the vent by turning the vent knob
counterclockwise all the way before
starting the engine. Close the vent by
turning the vent knob clockwise all
the way after stopping the engine.
CLOSE
VENT KNOB
OPEN
FUEL FILLER CAP
