PRE-OPERATION CHECK4.
Engine oil
Running the engine with insufficient oil can cause serious engine
damage.
Recommended oil
Using nondetergent oil or 2-stroke engine oil will shorten the engine’s
service life.
OIL FILLER NECK
OIL FILLER CAP
AMBIENT TEMPERATURE
UPPER LIMIT
Remove the oil filler cap and wipe the dipstick clean.
Insert the dipstick into the oil filler neck, but do not screw it in.
If the level is low, fill to the top of the oil filler neck with the recom-
mended oil.
Place the tiller on a level surface.
Use 4-stroke motor oil that meets or exceeds the requirements for API
service category SE or later (or equivalent). Always check the API
service label on the oil container to be sure it includes the letters SE or
later (or equivalent).
SAE 10W-30 is recommended for general
use. Other viscosities shown in the chart
may be used when the average
temperature in your area is within the
indicated range.
1.
2.
3.
4.
