24
Main clutch operation
Reduce engine rpm before operating main clutch operation.
Engaged
Disengaged
Disengaged
Engaged
···
···
DISENGAGED ENGAGE D
MAIN CLUTCH LEVERS
The clutch engages and disengages the power from the engine to the
transmission.
When the clutch lever is squeezed, the clutch is engaged and power is
transmitted. Squeeze the lever. The tool will be rotated.
When the lever is released, the clutch is disengaged and power is not
transmitted. Release the clutch lever. The tool will be stopped.
