Lighting switch operation
Tilling depth adjustment
(GE Type only)
HITCH PIN
HITCH BOX
DRAG BAR A
DRAG BAR B
PIN
BOLT
BOLT
BOLT
The switch changes the headlight and trailer working light.
Push upper: Working light comes ON and headlight goes OFF.
Install the hitch attachment in the hitch box with a hitch pin.
The tilling depth adjustment can be made by loosening the bolts
securing the drag bars A and B and sliding the drag bars up or down
as necessary.
Push lower: Headlight comes ON and working light goes OFF.
