1-7
H - Histogram Stretch
Increases the contrast of the transmitted image. Not available with some image formats.
0H No stretch (default)
1H Histogram stretch
I - Invert Image
Invert image is used to rotate the image around the X or Y axis.
Note: This feature should only be used with Image Ship - IMGSHP (page 1-4). Using this feature with Image Auto Crop
- IMGACP (page 1-4) may produce undesired results since Image Auto Crop attempts to rotate an image to a
horizontal display.
1ix Invert around the X axis (flips picture upside down)
1iy Invert around the Y axis (flips picture left to right)
IF- Noise Reduction
Used to reduce the salt and pepper noise in an image.
0if No salt and pepper noise reduction (default)
Example of Histogram Stretch at 0H: Example of Histogram Stretch at 1H:
Example of image
with Invert Image set to 1ix:
Example of image not
inverted:
Example of image
with Invert Image set to 1iy:
