Honeywell 748LC User Manual

DUAL TEC
®
Motion Sensors
10
DT-900
Long Range
DUAL TEC
®
“Designed specifically for
challenging commercial and
industrial applications.”
Features
• Dual coverage patterns
• Queue Logic event processing
• Selectable sensitivity modes
• Active infrared anti-mask system
• Digital fluorescent light filter
• Self-test and continuous supervision
• Anti-mask and trouble relay outputs
• Zero Clearance bug guard
• Tampered
• Available without anti-mask as DT-901
Specifications:
• Range: 90’ x 70’ and 50’ x 40’
• Microwave Freq: X-Band, 10.525GHz
• Optimal mounting height: 6’ to 12’
• Signal Proc.: Three sensitivity modes
• Temp comp: Standard
• Alarm relay: Form C
• Trouble/Anti-mask relays: Form B
• Input voltage: 10-15VDC
• Standby current: 35mA max. at 12V
• Indicators: Separate red, green, yellow
• LEDs
• Operating temp: 32°F to 120°F
• Dimensions: 8”W x 6.5”H x 6”D
DT-906
Long Range DUAL TEC
®
“Up to 200’ range for
commercial and industrial
corridor applications.”
Features
• Dual coverage patterns:
• Queue Logic Event Processing
• Selectable sensitivity modes
• Active infrared anti-mask system
• Digital fluorescent light filter
• Self-test and continuous supervision
• Anti-mask and trouble relay outputs
• Zero Clearance bug guard
• Available without anti-mask as DT-907
Specifications:
• Range: 200’ x 15’ and 120’ x 10’
• Microwave Freq: X-Band, 10.525GHz
• Optimal mounting height: 6’ to 12’
• Signal Proc.: Three sensitivity modes
• Temp comp: Standard
• Alarm relay: Form C
• Trouble/Anti-mask relays: Form B
• Input voltage: 10-15VDC
• Standby current: 35mA max. at 12V
• Indicators: Separate red, green, yellow
• LEDs
• Operating temp: 32°F to 120°F
• Dimensions: 8”W x 6.5”H x 6”D
IN04004 Sensor_Guide.qxd 7/19/05 12:40 PM Page 23
