Glassbreak Detectors
13
FG-1625R
Glassbreak Detector
“Same great performance
as the FG-1625 in a round
case that requires no
orientation or leveling.”
Features
• FlexCore™ processing
• Round case styling ideal for ceiling and
wall mount & easiest of all styles to
install
• Adjustable sensitivity
• No minimum range
• Remote Test Mode Enable
• Protected PCB
• Only sensor UL listed for coated and
double-pane glass
• Available with tamper/Form C
as FG-1625RT
Specifications:
• Range: 25’ maximum; no minimum
• Glass types: plate, tempered,
laminated, wired, coated, double-pane
• Sensitivity: four levels set via DIP switch
• Alarm relay: Form A
• Input voltage: 6-18VDC
• Standby current: 12mA typical at 12V
• Indicators: Red (alarm) and
green (test) LEDs
• Operating temp: 14°F to 122°F
• Dimensions: 4.25”Diameter x 0.9”D
• Tester: FG-701
FG-1608
Glassbreak Detector
with ValueGap
®
Magnetic Contact
“Two sensors in one
for great versatility,
performance and value.”
Features
• FlexCore™ processing
• Adjustable sensitivity
• No minimum range
• Remote Test Mode Enable
• Protected PCB with tamper switch
• Only sensor UL listed for coated and
double-pane glass
• Integrated reed switch and separate
actuator magnet
Specifications:
• Range: 8’ maximum; no minimum
• Glass types: plate, tempered,
laminated, wired, coated, double-pane
• Sensitivity: High or low.
• Magnetic Contact: 0.9” make/2.2”
break
• Alarm relay: Form A
• Input voltage: 6-18VDC
• Standby current: 13mA typical at 12V
• Indicators: Red (alarm) and
green (test) LEDs
• Operating temp: 14°F to 122°F
• Dimensions:
4.5”H x 1.3”W x 0.95”D (Glassbreak)
4.5”H x 0.5”W x 0.95”D (Magnet)
• Tester: FG-701
