Glassbreak Detectors
14
FG-1025Z
Glassbreak Detector with
Exclusion Zone
“Exclusive dual microphone
design provides unbeatable
false alarm immunity.”
Features
• Patented Time-of-Arrival processing with
dual microphones improves false alarm
immunity in its “Exclusion Zone”
• Remote Test Mode Enable
• Only sensor UL listed for coated and
double-pane glass
Specifications:
• Range: 25’ maximum; no minimum
• Glass types: plate, tempered,
laminated, wired, coated, double-pane
• Alarm relay: Form C
• Input voltage: 6-18VDC
• Standby current: 12mA typical at 12V
• Indicators: Red (alarm) and green (test)
LEDs
• Operating temp: 14°F to 122°F
• Dimensions: 4.25”Diameter x 0.9”D
• Tester: FG-701
FG-1625SN
V-Plex Glassbreak Detector
“Looks, sets up and
performs like the hardwired
version…ultimate glassbreak
performance for
V-Plex polling loop.”
Features
• Serial number addressable
• New hinged-case styling same
as FG-1625
• Set-up and performance identical
to FG-1625
Specifications:
• Range: 25’ maximum
• Glass types: plate, tempered,
laminated, wired, coated, double-pane
• Sensitivity: four levels set via
DIP switch
• Alarm relay: VPlex polling loop
• Input voltage: 7-11VDC for polling loop
• Standby current: <2mA
• Indicators: Red (alarm) and green (test)
LEDs
• Operating temp: 14°F to 122°F
• Dimensions: 4.5”H x 2.8”W x 1.0”D
• Tester: FG-701
IN04004 Sensor_Guide.qxd 7/19/05 12:35 PM Page 17
