21
2. Data carriers
2.1 Usable data carriers
Storage media are referred to as ID data carriers on which authorization data are saved. ID data
carriers are available in different geometrical shapes.
Only mifare cards and keychains can be used as data carriers.
To be able to use the encryption AES, mifare DESFire EV1 data carriers are needed.
For further information, refer to our current catalog.
The previous mifare classic data carrier can only be used parallel to EV1 data carriers if the
encryption AES is unused!
1. General
The mifare/DESFire EV1 readers "Accentic" are used as contactless readers and operating units in
access control and intrusion detection systems.
A combination of transponder and PIN can be used for performing functions via the keypad.
Additional functions (e.g. switching and control functions/macros) that can be activated via the
reader keypad can be defined in the programming of the control panel/evaluation unit.
Optical and acoustical acknowledgement is possible.
The housing faceplate can be changed subsequently (various colors are available).
Operating Instructions mifare/DESFire EV1 reader "Accentic" with/without keypad
F I
3
r
2
3
6
5
4
789
1
0
X
Influence on the read process by other data
carriers:
In order to prevent several data carriers
affecting the read process, ensure that the
desired data carrier is held separately, if
possible, in the reading range.
2.2 Correct application of data carriers
The data carrier should be held approximately in the of this range.middle
