Honeywell Bendix/King KFD 840 Primary Flight Display
Getting Started KFD 840 PG PN 7450-0840-01
2-6 Rev C May 28, 2010
© Honeywell International Inc. Do not copy without express permission of Honeywell
1. Course Menu
2. Crosswind (XW)
Headwind (HW)
Ground Speed (GS)
True Airspeed (TAS) /
Outside Air Temperature
(OAT)
3. Course Deviation indicator
(CDI) source
4. Magnetic Heading Indicator
5. Airspeed Tape
6. Airspeed Window
7. Airspeed Trend Line
8. Symbolic Aircraft
9. Bank Angle Scale
10. Flight Director
11. Vertical Guidance Window
12. Selected Altitude Bug
13. Selected Altitude Digits
14. Vertical Speed Digital
Readout
15. Vertical Speed Pointer
16. Altitude Window
17. Vertical Speed Indicator
(VSI)
18. Minimum Alert Altitude Bug
(MIN)
19. Glide slope/glide path
deviation pointer
20. MIN Altitude bug value
21. Barometric set Window
(BARO)
22. Heading bug value (HDG)
23. Bearing Source (O BRG /
◊ BRG )
GPS Navigator
Waypoint ID
Waypoint Distance
Waypoint Time
24. Heading Menu
25. Heading Bug (HDG)
26. Function Keys Menu
27. Course Pointer
