Honeywell Bendix/King KFD 840 Primary Flight Display
KFD 840 PG PN 7450-0840-01 Attitude Area
Rev D July 12, 2010 3-1
© Honeywell International Inc. Do not copy without express permission of Honeywell
3. ATTITUDE AREA
ATTITUDE DIRECTOR INDICATOR (ADI) WINDOW
The attitude director indicator ADI, centered in the top half of the
PFD, is shown below. The descriptions of the elements of the ADI
are given in the following paragraphs.
Figure 3-1 Attitude Director Window
