The circle bearing pointer is a single line pointer with the O symbol
between the center and the pointer tip. The diamond bearing pointer
is a double line pointer with the
◊ symbol between the center and
pointer tip. Therefore, when the pointers lie over each other, both
pointers and their identifying symbols are seen.
The full menu of navigation selections is displayed even if that
navigation unit is not installed.
Bearing Pointer Source
The bearing pointer source is selected
with the O BRG and ◊ BRG soft keys
on the unit. The digital bearing to the
station is displayed
next to the
selected source. If the bearing data is
invalid the readout displays amber
dashes.
If the bearing data is invalid, the bearing pointer is removed. If the
bearing source is GPS and magnetic variation data is invalid, the
bearing pointer is removed.
GPS Identifier and Distance
The waypoint identifier and
distance readout are displayed
near the upper right corner of
the HSI. The source for this
data is GPS only. The KFD 840
does not display any DME data.
Distance to the waypoint is displayed below the waypoint identifier.
The distance is displayed with a resolution of 1 nm, for distances of
100 nm or more and a resolution of 0.1 nm for distances less the 100
nm.
Time to the waypoint is displayed below the distance.
