6.3 UL, FM certified pressure switches
Switching capacity:
U = 24–240 V AC,
I = max. 5 A at cos ϕ = 1,
I = max. 0.5 A at cos ϕ = 0.6.
Maximum medium and ambient temperatures:
40 to +60°C (40 to +140°F).
Line entrance:
½" NPT conduit.
Cable diameter: AWG 24 to AWG 13,
0.02 to 0.07" (0.5 to 1.8 mm).
6.4 Adjusting range, switching hysteresis
6.4.1 CE certified pressure switches
Type
Adjusting
range*
mbar
Mean switching
differential at min. and
max. setting
mbar
Max. inlet pressure
p
max.
= withstand
pressure
mbar
Difference between
switching pressure and
possible reset
mbar
Deviation from the switching point during
testing pursuant to EN 1854
Gas pressure switch Air pressure switch
C6097A4110 1–10 0.25–0.4 500 – ± 15% ± 15%
C6097A4210 2.5–50 0.8–1.5 500 – ± 15% ± 15%
C6097A4310 30–150 3–5 600 – ± 15% ± 15%
C6097A4410 100–500 8–17 600 – ± 15% ± 15%
* Adjusting tolerance = ± 15% of the scale value.
Switching properties, see page 4 (Use).
▼
