Technical data
6.4.2 UL, FM certified pressure switches
Type
Adjusting range
*
"WC (mbar)
Mean switching
differential at min.
and max. setting
"WC (mbar)
Max. inlet pressure
Lock-off
Difference
between
switching
pressure and
possible reset
"WC (mbar)
Medium
NPT
connection
Switching
properties at
setpoint value
with without
venting line
psi (mbar) psi (mbar)
C6097A3004 0.4 – 4 (1–10) 0.1 – 0.16 (0.25–0.4) 8.5 (600) 7 (480) No – Air/gas 1/4"
NO-toCOM
connection is
interrupted if the
pressure drops
C6097A3012 1 – 20 (2.5–50) – 8.5 (600) 7 (480) Yes 0.4 – 0.8 (1–2) Air/gas 1/4"
C6097A3038 12 – 60 (30–150) – 8.5 (600) 7 (480) Yes 0.8 – 4.8 (2–12) Air/gas 1/4"
C6097A3053 1 – 20 (2.5–50) 0.3 – 0.6 (0.75–1.5) 8.5 (600) 7 (480) No – Air/gas 1/4"
C6097A3079 12 – 60 (30–150) 1.2 – 2 (3–5) 8.5 (600) 7 (480) No – Air/gas 1/4"
C6097A3095 0.4 – 4 (1–10) – 8.5 (600) 7 (480) Yes
0.16 – 0.4
(0.4–1)
Air/gas 1/4"
C6097A3111 40 – 200 (100–500) – 8.5 (600) 7 (480) Yes 2 – 7.2 (5–18) Air/gas 1/4"
C6097A3137 40 – 200 (100–500) 3.2 – 6.8 (8–17) 8.5 (600) 7 (480) No – Air/gas 1/4"
C6097B3002 12 – 60 (30–150) – 8.5 (600) 7 (480) Yes 0.8 – 4.8 (2–12) Air/gas 1/4"
NC-toCOM
connection is
interrupted if the
pressure rises
C6097B3028 1 – 20 (2.5–50) – 8.5 (600) Yes 0.4 – 0.8 (1–2) Air/gas 1/4"
C6097B3051 40 – 200 (100–500) – 8.5 (600) Yes 2 – 7.2 (5–18) Air/gas 1/4"
C6097B3085 12 – 60 (30–150) 1.2 – 2 (3–5) No – Air/gas 1/4"
C6097B3101 40 – 200 (100–500) 3.2 – 6.8 (8–17) No – Air/gas 1/4"
C6097B3119 1 – 20 (2.5–50) 0.3 – 0.6 (0.75–1.5) No – Air/gas 1/4"
* Adjusting tolerance = ± 15% of the scale value.
For further information, see page 4 (Use).
