Chapter 2 SYESTEM DIAGRAM
2.1 SYESTEM DIAGRAM
Chapter 3 Hardware
3.1 H.264 standalone 4CH/8CH/16CH DVR
3.1.1 Hard disk Installation
For the first use, please install the hard disk
○
1
Remove the screws on both
○
2
extracted from the next cover up
○
3
connect hard disk and mother board
sides of shell
