Firmware Upgrades
Firmware Upgrade Manual Part No.: 4417596_Rev11
1 - 4 CIU 888
b) Remove the key from the key switch and store it.
On the CIU 888 display, the status of the key switches changes from
‘Locked’ to ‘Unlocked’ (see FIGURE 1-4).
FIGURE 1-4 CIU 888 display: Configuration settings are unlocked
3. On the PC/laptop connected to the CIU 888, launch the browser.
4. Enter the IP address of the CIU 888 in the address bar of the
browser. The IP address is 192.168.1.1. Next, press the Enter key.
The CIU 888 Login window is displayed (see FIGURE 1-5).
FIGURE 1-5 CIU 888 Login window
5. Enter the username and password to log into the CIU 888. The
username is ciuadmin. Next, click LOG IN.
After entering a valid username and password, the CIU 888 Web
interface is displayed.
