CLASS 320 METER
39 62-0397-02
10.3.1 Date & Time
To change the date and time, complete the following steps:
1. Press the MENU button.
2. The following screen will appear:
3. Press the SELECT button. The date and time screen will appear, and the 2 digit
month will be blinking.
4. Use UP or DOWN button to make changes, press SEL button to advance to the
next field. Press MENU button to return to main menu.
5. If changes were made, you’ll be asked to save, press UP or DOWN to select Y or
N; press SEL to proceed returning to main menu. In main menu, select EXIT to
get out of programming mode and return to normal display mode.
Date & Time
Device ID
Reset KW/KWH Read
Exit
DATE: 02-16-2012
TIME: 01:57:36
To Next Page
