CLASS 320 METER
62-0397-02 40
10.3.2 Device I.D.
To change Device I.D., complete the following steps:
1. Press the MENU button.
2. The following screen will appear:
3. Use the UP and DOWN buttons to select the Device ID line.
Press the SELECT button. The Device I.D. screen will appear.
4. Locate the number to be changed in the menu, press and hold Button 4 (Down
Button) for 3 seconds, release the button, the last digit for this number blinks,;
5. To change the number of the digit, use Button 3 (Up Button) to cycle
through 0 to 9.
6. Press Button 4 to move to the next digit, and repeat Step 5.
7. To exit the mode of changing number by digit, press Select Button;
To save the new number, press Main Menu Button and select “Y” to save.
Date & Time
Device ID
Reset KW/KWH Read
Exit
To Next Page
